cf_sort	No	Center Feq.	Part No	Filter Type	Type	Impedance	Band Width	Insertion Loss	Return Loss	Attenuation	Dimension	pdf
11000		11000MHz	MBP-C11000_3000MA-A-R0	Band Pass Filter	SMD	50Ohm	3000MHz	3.5dB	10dB	60dBc Min @ DC ~ 7500MHz 40dBc Min @ 7500 ~ 8500MHz 45dBc Min @ 13500 ~ 14500MHz 60dBc Min @ 14500 ~ 23000MHz 50dBc Min @ 23000 ~ 24000MHz	7.5 X 4 X 2mm	pdf
11550		11550MHz	MBP-C11550_530MT-B-R0	Band Pass Filter	SMD	50Ohm	530MHz	3.5dB	12dB	50dBc Min @ 100 ~ 10000MHz 30dBc Min @ 12500 ~ 13600MHz 60dBc Min @ 13600 ~ 19000MHz 50dBc Min @ 19000 ~ 20000MHz	12.0 X 5.0 X 2.5mm	pdf
12000		12GHz	MBP-C12_4GM-A-R0	Band Pass Filter	SMD	50Ohm	4GHz	1.5dB	10dB	20dB Min @ 9GHz 25dB Min @ 15.4GHz	6.2 X 4.0 X 1.0mm	pdf
13000		13000MHz	MBP-C13000_3000MA-A-R0	Band Pass Filter	SMD	50Ohm	3000MHz	4dB	10dB	60dBc Min @ DC ~ 9500MHz 40dBc Min @ 9500 ~ 10500MHz 45dBc Min @ 15500 ~ 16500MHz 60dBc Min @ 16500 ~ 24000MHz	7.5 X 3.5 X 2mm	pdf
14500		14.5GHz	MBP-C14.5_7GM-A-R0	Band Pass Filter	SMD	50Ohm	7GHz	1.5dB	10dB	25dB Min @ 10GHz 25dB Min @ 20GHz	6.2 X 4.0 X 1.0mm	pdf
15000		15000MHz	MBP-C15000_3000MA-A-R0	Band Pass Filter	SMD	50Ohm	3000MHz	4dB	10dB	60dBc Min @ DC ~ 11500MHz 40dBc Min @ 11500 ~ 12500MHz 45dBc Min @ 17500 ~ 18500MHz 60dBc Min @ 18500 ~ 24000MHz	7.5 X 3 X 2mm	pdf
1600		1600MHz	MBP-C1600_1200MB-A-R0	Band Pass Filter	BEAD	50Ohm	1200MHz	3.5dB	12dB	45dB Min @ DC ~ 700MHz 45dB Min @ 3200 ~ 4200MHz 60dB Min @ 4200 ~ 6000MHz	15.0 X 8.0 X 6.0mm	pdf
16000		16GHz	MBP-C16_4GM-A-R0	Band Pass Filter	SMD	50Ohm	4GHz	1.2dB	10dB	20dB Min @ 12.6GHz 20dB Min @ 20GHz	10.5 X 4.0 X 1.0mm	pdf
17000		17000MHz	MBP-C17000_3000MA-A-R0	Band Pass Filter	SMD	50Ohm	3000MHz	5dB	10dB	60dBc Min @ DC ~ 13500MHz 40dBc Min @ 13500 ~ 14500MHz 45dBc Min @ 19500 ~ 20500MHz 60dBc Min @ 20500 ~ 24000MHz 45dBc Min @ 19200MHz	7.5 X 3 X 2mm	pdf
2750		2.75GHz	MBP-C2.75_1.5GM-A-R0	Band Pass Filter	SMD	50Ohm	1.5GHz	1dB	12dB	19dB Min @ 1.8GHz 15dB Min @ 3.85GHz	7.0 X 13.5 X 1.45mm	pdf
3000		3000MHz	MBP-C3000_2400MB-A-R0	Band Pass Filter	BEAD	50Ohm	2400MHz	3.5dB	12dB	45dB Min @ DC ~ 800MHz 45dB Min @ 5200 ~ 6200MHz 60dB Min @ 6200 ~ 8000MHz	15.0 X 8.0 X 6.0mm	pdf
4750		4.75GHz	MBP-C4.75_2.5GM-A-R0	Band Pass Filter	SMD	50Ohm	2.5GHz	1dB	12dB	10dB Min @ 3.2GHz 15dB Min @ 6.6GHz	6.7 X 9.0 X 1.4mm	pdf
4900		4900MHz	MBP-C4900_2200MA-A-R1	Band Pass Filter	SMD	50Ohm	2200MHz	3dB	10dB	60dBc Min @ DC ~ 1800MHz 40dBc Min @ 1800 ~ 2800MHz 45dBc Min @ 7000 ~ 8000MHz 60dBc Min @ 8000 ~ 9000MHz TBD Min @ 9000 ~ 24000MHz	7.5 X 7 X 2mm	pdf
7000		7000MHz	MBP-C7000_3000MA-A-R0	Band Pass Filter	SMD	50Ohm	3000MHz	3.5dB	10dB	60dBc Min @ DC ~ 3500MHz 40dBc Min @ 3500 ~ 4500MHz 45dBc Min @ 9500 ~ 10500MHz 60dBc Min @ 10500 ~ 13000MHz TBD Min @ 13000 ~ 24000MHz	7.5 X 6 X 2mm	pdf
7625		7625MHz	MBP-C7625_2250MT-B-R0	Band Pass Filter	SMD	50Ohm	2250MHz	2.8dB	15dB	35dBc Min @ 5700 & 9550MHz 60dBc Min @ 10590 & 12340MHz 45dBc Min @ 12340 ~ 13400MHz 40dBc Min @ 50 ~ 4500MHz	10.0 X 5.5 X 2.5mm	pdf
8500		8.5GHz	MBP-C8.5_5GM-A-R0	Band Pass Filter	SMD	50Ohm	5GHz	1.5dB	10dB	10dB Min @ 5.4GHz 15dB Min @ 12GHz	6.4 X 6.0 X 1.45mm	pdf
8000		8GHz	MBP-C8_4GM-A-R0	Band Pass Filter	SMD	50Ohm	4GHz	1.5dB	10dB	15dB Min @ 5.4GHz 20dB Min @ 11GHz	6.4 X 6.0 X 1.45mm	pdf
9000		9000MHz	MBP-C9000_3000MA-A-R0	Band Pass Filter	SMD	50Ohm	3000MHz	3.5dB	10dB	60dBc Min @ DC ~ 5500MHz 40dBc Min @ 5500 ~ 6500MHz 45dBc Min @ 11500 ~ 12500MHz 60dBc Min @ 12500 ~ 17000MHz TBD Min @ 17000 ~ 24000MHz	7.5 X 5 X 2mm	pdf
9375		9375MHz	MBP-C9375_2250MT-B-R0	Band Pass Filter	SMD	50Ohm	2250MHz	3.5dB	15dB	35dBc Min @ 7450 & 11300MHz 60dBc Min @ 12340 & 14090MHz 45dBc Min @ 14090 ~ 15150MHz 40dBc Min @ 50 ~ 6250MHz	10.0 X 5.5 X 2.5mm	pdf
